Chapter 5 ONLINE HELP SOPAS
LECTOR®620
76 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
5.8.2.3 Separate codes dependent on sensor
Separate codes dependent on sensor
5.8.3 Output control
The Output control tab contains the parameters used to determine the timings for output-
ting the Output format 1 and Output format 2 data.
5.8.3.1 Output control
The Output control group contains the parameters used to define the timeline for data out-
put for Output format 1 and Output format 2.
5.8.3.1.1 Control
Control
5.8.3.1.2 Output time
You can use the Output time parameter to define when the reading results are to be output.
• E
ND OF TRIGGER: The reading results of all codes are output as soon as the reading gate is
closed. As a result, the data is output at a definable point in time.
• A
S SOON AS POSSIBLE: The reading results of a code are output immediately after code iden-
tification (even if the reading gate is still open). As a result, data can immediately be pro-
cessed further.
• N
EW LABEL: The reading results of a code are output directly after identification of a code.
However, before the same code can be output again, another code must be identified. As a
result (e.g. during manual reading), you can prevent a code from being identified multiple
times and the data being output again.
• E
ND OF LABEL: The reading results of a code are output as soon as a code leaves the rea-
ding area of the LECTOR
®
620.
In operating mode, image transmission and diagnosis are only available for the E
ND OF TRIG-
GER setting.
5.8.3.1.3 Output condition
If the A
S SOON AS POSSIBLE value is selected for the Output time parameter, you can use the
Output condition parameter to select the condition for data output.
• G
OOD READ: The reading results are output if the reading was successful.
• C
ONDITION MATCH1: The reading results are output if the read code corresponds to the
matchcode from C
ONDITION MATCH1.
• C
ONDITION MULTCODES1: The reading results are output if the number of read codes corre-
sponds to the required number from C
ONDITION MULTCODES1.
• C
ONDITION TEACHIN1: The reading results are output if the read code corresponds to the
matchcode from C
ONDITION TEACHIN1.
• C
ONDITION TEACHIN2: The reading results are output if the read code corresponds to the
matchcode from C
ONDITION TEACHIN2.
