Chapter 5 ONLINE HELP SOPAS
LECTOR®620
152 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
5.10.13.1.6 Length
If the T
IMER/TRACKING condition is selected under the Function (Off) parameter, you can use
the Length parameter to enter the duration for which the digital output remains activated.
The unit can be selected in the Control parameter.
5.10.13.2 Output/Result 2
The Output/Result 2 group contains the parameters for adjusting digital output 2.
5.10.13.2.1 Active
The event that activates the digital output is selected via the Active parameter.
• SOPAS
COMMAND: The output is activated via a command. This allows defined statuses to
be displayed by a connected indicator lamp via a corresponding command from the control
(PLC).
• D
EVICE READY: The output is activated as soon as the LECTOR
®
620 is ready for use.
• G
OOD READ: The output is activated when the read is successful.
• N
O READ: The output is activated when the read is unsuccessful.
• T
EACH-IN 1 OK: The output is activated when the MATCH CODE TEACH-IN 1 has been suc-
cessfully taught in.
• T
EACH-IN 1 NOK: The output is activated if the MATCH CODE TEACH-IN 1 has not been suc-
cessfully taught in.
• T
EACH-IN 2 OK: The output is activated when the MATCH CODE TEACH-IN 2 has been suc-
cessfully taught in.
• T
EACH-IN 2 NOK: The output is activated if the MATCH CODE TEACH-IN 2 has not been suc-
cessfully taught in.
• E
XTERNAL LIGHTING: External lighting is connected to the output and can be switched on and
off by the device.
• M
ATCH 1 CONDITION: The output is activated when the code that has been read corresponds
to the M
ATCH 1 CONDITION match code.
• M
ULTICODES1 CONDITION: The output is activated when the number of codes that have been
read corresponds to the number specified by the M
ULTICODES1 CONDITION.
• T
EACH-IN1 CONDITION: The output is activated when the code that has been read corre-
sponds to the T
EACH-IN1 CONDITION match code.
• T
EACH-IN2 CONDITION: The output is activated when the code that has been read corre-
sponds to the T
EACH-IN2 CONDITION match code.
The behavior of the external lighting and the switch type is set under Illumination.
5.10.13.2.2 Function (Off)
The Function (Off) parameter is used to select the event for which the digital output is deac-
tivated.
• T
IMER/TRACKING: The output is deactivated after a certain period of time (Length).
• N
EXT OBJECT TRIGGER: The output is deactivated as soon as the next reading gate is opened.
