ONLINE HELP SOPAS Chapter 5
LECTOR®620
Parameters
8013778/Y269/2013-11-27 © SICK AG · Germany · All rights reserved · Subject to change without notice 47
5.7.2.8 GS1 DataBar
If the GS1 DataBar parameter is activated, decoding is activated for the DataBar 14,
DataBar Expanded, and DataBar Limited active code types. This requires the Pharmacode
code type to be deactivated.
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
5.7.2.9 Pharmacode
If the Pharmacode parameter is activated, decoding is activated for the code type.
All other code types are deactivated.
• Code name: Pharmacode (binary)
• Character set: Numeric characters (integers between 3 and 131070)
• Structure: Wide bars: 1, narrow bars: 0 (main code and additional code can have different
colors)
• Intrinsic reliability: High
• Space required: Low
• Standard: Barcode standard of the company Laetus
• Area of application: Packaging check in the pharmaceutical industry (agreement with re-
ference code from a code list)
5.7.2.10 Stacked codes
The Stacked codes group contains all the parameters for configuring the stacked codes (se-
veral barcodes stacked in rows one above the other, with the same start and stop charac-
ter).
5.7.2.10.1 PDF417
If the PDF417 parameter is activated, decoding is activated for the code type.
As only activated code types are processed, you can increase the processing speed by
specifically activating/deactivating the required code types.
• Code name: PDF417
• Character set: 2710 numeric, 1850 alphanumeric, 1400 ASCII or 1108 ISO characters
