5.8.6.2 Filters/Sorters for Output Format2
You can use the graphical interface of the Filters/Sorters for Output Format2 group to re-
strict (filter) data for output of the reading results and define the sequence in which the data
is output (sort). By combining filters and sorters, you can therefore individually influence
data output.
Any number of filters and sorters can be graphically arranged for this between the device
and PC. The filters can also be arranged in parallel.
You can add further filters and sorters by pulling down the corresponding symbols. If you
move the symbols while holding down the Ctrl key, you can copy filters or sorters. You can
delete the symbols by moving them to the trash. Selected symbols can also be removed by
pressing the D
EL. key.
During filtering, you can use the button to define the variable and condition for filtering.
Example: (CL) C
ODE LENGTH = 10: Only codes with a code length of exactly 10 characters are
output.
During sorting, you use the button to select the variable used to sort the reading results.
You can also choose between sorting in ascending and descending order.
Example: (CL) C
ODE LENGTH - ASCENDING: The codes with the shortest code length are output
first.
For more information, see the F1 help.
Items Description
BC - Code content Code content of read code
CL - Code length Code length of read code
X - X pos. absolute Code distance to trigger position X in mm
Y - Y pos. absolute Code distance to trigger position Y in mm
Z - Z pos. absolute Code distance to trigger position Z in mm
CS - Code security Indicates how 1D codes was read
VAL - Code valid (1 or 0) Output whether read code is valid/ whether the
set condition is fulfilled (e.g. whether number of
multireads was fulfilled)
ID - Code type Code type of read code
ON - Internal object number Number of actual object (summed up number of
scanned objectes)
CC - Code count Number of read codes within reading gate
VCC - Number of valid codes Number of valid codes within reading gate
More code-realted items… Description
IWA - Code ID Code type according to allignment number
(ASCII position of code ID which is a alphabetical
number of the respective code type)
