Chapter 5 ONLINE HELP SOPAS
LECTOR®620
74 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
5.7.14.5.3 Application identifier marking
If the Application identifier marking parameter is activated, the
APPLICATION IDENTIFIER are out-
put in parentheses in the output format.
As a result of the
APPLICATION IDENTIFIERS the following values of the code contents are assi-
gned to a defined property. As a result, you can display the data of a code (e.g. expiry date,
batch number, date of manufacture etc.) in standardized form.
5.7.15 PDF 417
If the PDF 417 parameter is activated, decoding is activated for the corresponding code ty-
pe. The configuration tab for the corresponding code type can be seen and opened in
SOPAS ET.
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
• Code name: PDF 417
• Character set: 2710 numeric, 1850 alphanumeric, 1400 ASCII or 1108 ISO characters
• Symbol size: 3 to 90
• Intrinsic safety: Very high (error correction)
• Spatial requirements: Very low
• Standard: ISO/IEC 15438
• Area of application: Parcel and postal service
5.7.15.1 General
General (PDF)
USP 1FH Unit separator
SPC 20H Space
DEL 7FH Delete
User defined User defined [HEX]
Nothing Nothing
Special characters… Description
