Chapter 3 ONLINE HELP SOPAS
LECTOR®620
20 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Online images
• The module width is the dimension of the smallest code element (bar of a bar code or dot
in a data matrix code) in pixels.
• The module height is the length of a bar of a bar code or the height of a dot in the data
matrix code.
3.1.3 Statistics
The display fields of the Statistics group are used to evaluate the reading results across all
triggers since the device was started or since the last reset.
The reading results during setup of the LECTOR
®
620 are not taken into consideration in the
statistics.
Reading gates The number of all triggers since the device was started or since the last reset are displayed
in the Reading gates display field.
The triggers during setup of the LECTOR
®
620 are not taken into consideration in the stati-
stics.
Good Reads The number of triggers for which the condition for Good Read was met is displayed in the
Good Reads display field.
The triggers during setup of the LECTOR
®
620 are not taken into consideration in the stati-
stics.
No Reads The number of triggers for which the condition for Good Read was NOT met is displayed in
the No Reads display field.
The triggers during setup of the LECTOR
®
620 are not taken into consideration in the stati-
stics.
Read rate The proportion of triggers for which the condition for Good Read compared to all triggers is
displayed as a % in the Read rate display field.
The triggers during setup of the LECTOR
®
620 are not taken into consideration in the stati-
stics.
Reset The Reset button is used to delete the values of the Reading gates, Good Reads, No Reads,
and Read rate display fields.
