ONLINE HELP SOPAS Chapter 5
LECTOR®620
Parameters
8013778/Y269/2013-11-27 © SICK AG · Germany · All rights reserved · Subject to change without notice 57
• Intrinsic reliability: High
• Space required: Low
• Standard: DIN/EN 797
• Area of application: Food and consumer goods in the USA and Canada
5.7.8.2.2 UPC E
If the UPC E parameter is activated, decoding is activated for the code type.
As only activated code types are processed, you can increase the processing speed by
specifically activating/deactivating the required code types.
• Code name: UPC E (Universal Product Code) (4-value)
• Character set: 8 numeric characters
• Structure: System ID (always 0), 2 characters for country prefix, 4 characters for manuf-
acturer and article, 1 character as check digit
• Intrinsic reliability: High
• Space required: Low
• Standard: DIN/EN 797
• Area of application: Food and consumer goods in the USA and Canada
5.7.8.2.3 UPC E extended
If the UPC E extended parameter is activated, 8-character codes of code type UPC E are au-
tomatically converted to 12-character codes. (Code type Pharmacode must be deactivated.)
5.7.8.3 EAN
The GTIN 8 / EAN 8 and GTIN 13 / EAN 13 code types can be activated or deactivated under
the EAN group.
5.7.8.3.1 GTIN 8 / EAN 8
If the GTIN 8 / EAN 8 parameter is activated, decoding starts for the relevant code type.
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
• Code name: GTIN 8 / EAN 8 (European Article Numbering) (4-value)
• Character set: 8 numerical characters (check digits: last two characters)
