Chapter 5 ONLINE HELP SOPAS
LECTOR®620
112 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
5.8.9.1.1 Resetting counter statuses
Pressing the Resetting counter statuses button resets all counters.
To reset the permanent flash memory in addition to this, the Saving current counter status-
es button must also be pressed.
5.8.9.1.2 Saving current counter statuses
Pressing the Saving current counter statuses button saves all values to the device's flash
memory. This means the values are available without a permanent supply voltage, i.e., the
values are still saved after restarting the device.
5.8.9.1.3 Application counter
Various events can be selected as application counters.
Counter Description
Deactivated No event counting
Input 1 Number of input 1 activations
Input 2 Number of input 2 activations
Ext. input 1 Number of external input 1 activations
Ext input 2 Number of external input 2 activations
Output 1 Number of output 1 activations
Output 2 Number of output 2 activations
Output 3 Number of output 3 activations
Output 4 Number of output 4 activations
Ext. output 1 Number of external output 1 activations
Ext. output 2 Number of external output 2 activations
Condition match 1 Number of codes read that correspond to the match code
from
BEDINGUNG MATCH 1
Condition MultCodes1 Number of codes read that correspond to the number speci-
fied in BEDINGUNG MULTCODES1
Condition TeachIn1 Number of codes read that correspond to the match code
from BEDINGUNG TEACHIN1
Condition TeachIn2 Number of codes read that correspond to the match code
from BEDINGUNG TEACHIN2
(NZ) Number of mismatches Number of codes read that do not fulfill the match conditi-
ons
(NY) Number of no matches Number of objects without a match
(GNC) Global number of codes Number of codes read
(NRVB) Global number of valid
released codes
Number of valid released codes
(NC) ANZ. LESETORE
Number of reading gates
(SCGR) Superordinate counter: Good
Read
Superordinate Good Read counter; remains in case of a new
parameterization (reset via power cycle)
(SCNR) Superordinate counter: No
Read
Superordinate No Read counter; remains in case of a new
parameterization (reset via power cycle)
(RR) Read rate Ratio between Good Reads (SCGR) and number of reading
gates
