ONLINE HELP SOPAS Chapter 5

LECTOR®620

Parameters

5.7.6.2.2 Interval

The Interval parameter can be used to define the minimum and maximum code length. Only

codes with a code length between these two values are read.

By defining a minimum and maximum code length, you restrict the range of codes to be

read. This can lead to a reduction in the decoding time.

5.7.6.2.3 Fixed length

The Fixed length parameter is used to define several fixed code lengths. Only codes with one

of these defined code lengths are read.

By defining certain permitted code lengths, you restrict the range of codes to be read.

This can lead to a reduction in the decoding time.

5.7.7 Code 39

If the Code 39 parameter is activated, decoding is activated for the corresponding code ty-

pe. The configuration tab for the corresponding code type can be seen and opened in

SOPAS ET.

As only activated code types are processed, you can increase the processing speed by

deactivating the code types that are not being used.

• Code name: Code 39 (two-value)

• Character set: 43 alphanumeric characters (10 digits, 26 letters, 7 special characters)

• Structure: 9 code elements (5 bars, 4 gaps) – 3 wide and 6 narrow

• Intrinsic safety: Average

• Spatial requirements: High

• Standard: ISO/IEC 16388

• Area of application: Parcel and postal service

5.7.7.1 General

Reading processes such as the number of necessary multireads, regulations for dealing

with the start and stop characters, or check digit tests are configured under the General

group.

5.7.7.1.1 Multiread

You use the Multiread parameter to define a minimum number of G

OOD READ required for a

reading to be output as a G

OOD READ.

By defining a minimum number of readings, you reduce the likelihood of misinterpretations

for codes with poor printing quality or a low contrast, and increase reading reliability.
