ONLINE HELP SOPAS Chapter 5
LECTOR®620
Parameters
8013778/Y269/2013-11-27 © SICK AG · Germany · All rights reserved · Subject to change without notice 77
5.8.3.1.4 Data output mode
The Data output mode parameter is used to define the frequency of data output.
• S
INGLE: The reading results are output once.
• M
ULTIPLE: The reading results are initially output once. After a certain period of time (Label
timeout or Condition timeout), the data is output again. With a suitable setting, you can dif-
ferentiate between different objects with identical codes.
Label timeout If the A
S SOON AS POSSIBLE value is selected for the Output time parameter, you can use the
Label timeout parameter to define the duration up to renewed output of the data. During
this period, the data is output again as long as the code is in the reading area.
The unit can be selected in the Output delay parameter.
Condition timeout If the A
S SOON AS POSSIBLE value is selected for the Output time parameter, you can use the
Condition timeout parameter to define the duration up to renewed output of the data. Du-
ring this period, the data is output again as long as the condition for data output (Output
condition) is met.
The unit can be selected in the Output delay parameter.
5.8.3.1.5 Label timeout
Label timeout
5.8.3.1.6 Condition timeout
Condition timeout
5.8.3.1.7 Delay
If the E
ND OF TRIGGER value is selected for the Output time parameter, the Delay parameter
can be used to hold back the data for a certain period after the reading gate has been
closed. This allows the timings to be adapted to the control (PLC).
The unit can be selected via the Output delay parameter.
A long delay time slows down the image output. The image output can speed up if the
delay values are low.
5.8.3.1.8 Output delay
The Output delay parameter is used to choose between configuration with units of length or
configuration with units of time for the Delay, Label timeout, Condition timeout, and
Timeout parameters
• T
RACK CONTROLLED: The entries for the parameters are made in mm.
• T
IME CONTROLLED: The entries for the parameters are made in ms.
