Chapter 5 ONLINE HELP SOPAS
LECTOR®620
126 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
For the reading diagnosis, the following information is combined in a diagnosis string for
each reading gate:
• TT: Length of the reading gate in ms
• OTL: Trigger length in mm
• CC: Number of codes per reading gate
• FC: Focus length in mm
• Code content
• Code type
For 1D code types
• CL: Code length
• RSD1DV: Ratio of scans to decoded scans (reading reliability) in %
For 2D code types
• SZ: Symbol size
• RES: Dot resolution in pixels
• CTV: Symbol contrast in %
• UECV: Decodability (unused error correction) in %
• MC: Number of multireads per code
5.10.5.2.2 RDT ID
RDT ID
5.10.5.2.3 Enable heartbeat
If the Enable heartbeat parameter is activated, a signal is output via the interface at regular
intervals (Heartbeat interval). The availability of the LECTOR
®
620 can therefore be checked
via the interface.
5.10.5.2.4 Heartbeat interval
The Heartbeat interval parameter is used to define the time between the heartbeat signals
in s.
5.10.5.2.5 Restart interval on sending
If the Restart interval on sending parameter is activated, the time between the heartbeat
signals starts again after output of the reading results.
5.10.5.2.6 Handling input data
The Handling input data parameter is used to define how the sensor uses data received at
the serial aux interface.
• N
O INPUT DATA: No data is received at the interface.
• D
ATA FORWARDING: The incoming data is forwarded to another interface. Possible target in-
terfaces are serial aux, serial host, Ethernet aux, and Ethernet host.
• A
UXILIARY INPUT: The incoming data is output to all configured interfaces in the same way
as a specific reading result.
