Chapter 3 ONLINE HELP SOPAS

LECTOR®620

Online images

3 Online images

The recorded images are displayed on the Online images tab.

The display enables you to look at the images in detail and assess the recording quality. By

modifying the configuration and comparing the recorded images, you can optimize the rea-

ding properties and the position of the LECTOR

620.

The reading results are displayed in Code infobox.

For an evaluation of the current setting for the contrast, the identified codes are displayed

with different colors:

• Green (excellent): Contrast between 55 % and 100 %

• Yellow (good): Contrast between 20 % and 55 %

• Red (poor): Contrast less than 20 %

3.1 Online images

The most recently recorded image is displayed in the main view of the Online images group.

The display enables you to look at the images in detail and assess the quality of the shot.

By modifying the configuration and comparing each of the images taken, you can optimize

the reading properties and the position of the LECTOR

620.

The reading results are displayed in the Code infobox.

For an evaluation of the current setting for the contrast, the identified codes are displayed

with different colors:

• Green (excellent): Contrast between 55% and 100%

• Yellow (good): Contrast between 20% and 55%

• Red (poor): Contrast less than 20%

Operation If you press the Operation button, the mode for setting up the LECTOR

620 is stopped, and

the operating mode of the LECTOR

620 is activated in accordance with the current configu-

ration.

In Image history, the recorded images are displayed one after the other. The reading

results are displayed in the Code infobox. The reading results for the last readings are com-

bined in the display fields for the Statistics group.

For an evaluation of the current setting for the contrast, the identified codes are displayed

with different colors:

• Green (excellent): Contrast between 55% and 100%

• Yellow (good): Contrast between 20% and 55%

• Red (poor): Contrast less than 20%
