Chapter 5 ONLINE HELP SOPAS
LECTOR®620
92 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
IN - Increment Increment value at start of reading gate
FC - Focus position Reading distance which is set in mm
RSD1DV - Ratio scans/decoded scans value Ratio between "S1D - Scans auf 1D Codes" to
"S1D1 - Decoded scans on 1D codes". Grading
to verify the reading stability on 1D codes
VTH - Threshold of CS for code to become valid Valid if CS>=VTH which means that number of
scans = VTH*2 (for 1D codes only)
S1D - Scans on 1D codes Number of scans on 1D codes
SD1D - Decoded scans on 1D codes Number of decoded scans on 1D codes
FCT - Code type full description Code type, elaborated description
DI - Dimension Indicates wheter it is a 1D code or a 2D code
X1 - Code corner 1 X Pixel position of code corner 1X
Y1 - Code corner 1 Y Pixel position of code corner 1Y
X2 - Code corner 2 X Pixel position of code corner 2X
Y2 - Code corner 2 Y Pixel position of code corner 2Y
X3 - Code corner 3 X Pixel position of code corner 3X
Y3 - Code corner 3 Y Pixel position of code corner 3Y
X4 - Code corner 4 X Pixel position of code corner 4X
Y4 - Code corner 4 Y Pixel position of code corner 4Y
CPX - X position relative to image origin Code center X in pixels
CPY - Y position relative to image origin Code center Y in pixels
AN2 - Tilt angle Tilt angle for 1D codes and 2D codes relative to
the horizontal (angular degree)
MCR - Ratio between image and multicount [in
%]
Ratio between images and successful multi-
reads
X2D - X 2D Symbol size (number of modules) in X direction;
for 2D codes only
Y2D - Y 2D Symbol size (number of modules) in Y direction;
for 2D codes only
MX2 - Modul X size Average modul size in X direction in mm; for 2D
codes only
MY2 - Modul Y size Average modul size in Y direction in mm; for 2D
codes only
IV2 - Inverse (boolean) Code was read inverted
MD2 - Mirrored (boolean) Code was read mirrored
CTG - ISO16022/ISO15415 Symbol contrast
grade
Grading for symbol contrast according to ISO/
IEC16022 and ISO/IEC15415. Checks the con-
trast between brigth and dark dots in the code.
CTG - ISO16022/ISO15415 Symbol contrast
value
Value for symbol contrast according to ISO/
IEC16022 and ISO/IEC15415. Checks the con-
trast between brigth and dark dots in the code.
More… Description
PGV - ISO16022/ISO15415 Print growth value Grading for print growth according to ISO/
IEC16022 and ISO/IEC15415. Checks the diffe-
rence between the ideal and the actual dot size.
PGG - ISO16022/ISO15415 Print growth grade Value for print growth according to ISO/
IEC16022 and ISO/IEC15415. Checks the diffe-
rence between the ideal and the actual dot size.
More code-realted items… Description
