ONLINE HELP SOPAS Chapter 5
LECTOR®620
Parameters
8013778/Y269/2013-11-27 © SICK AG · Germany · All rights reserved · Subject to change without notice 93
ANUV - ISO16022/ISO15415 Axial non-unifor-
mity value
Value for axial non-uniformity according to ISO/
IEC16022 and ISO/IEC15415. Checks the ration
between length and width of the code. If the
code is streched or compressed in length or
width, it is given a poor rating for its axial non-
linearity.
ANUG - ISO16022/ISO15415 Axial non-unifor-
mity grade
Grading for axial non-uniformity according to
ISO/IEC16022 and ISO/IEC15415. Checks the
ration between length and width of the code. If
the code is streched or compressed in length or
width, it is given a poor rating for its axial non-
linearity.
UECV - ISO16022/ISO15415 Unused error cor-
rection value
Value for unused error correction according to
ISO/IEC16022 and ISO/IEC15415. Checks how
much redundant data had to be used during rea-
ding to decode the data content. The best grade
is achieved if redundancy was not required at all.
UECG - ISO16022/ISO15415 Unused error cor-
rection grade
Grading for unused error correction according to
ISO/IEC16022 and ISO/IEC15415. Checks how
much redundant data had to be used during rea-
ding to decode the data content. The best grade
is achieved if redundancy was not required at all.
OSG - Overall symbol grade Overall symbol grade according to ISO/
IEC16022 and ISO/IEC15415. This grading can
be considered as a summary of the criteria. The
poorest af all the criteria used is always output.
GNUV - ISO15415 Grid non-uniformity value Grading for grid non-uniformity according to ISO/
IEC15415. A grid is placed over the code using
the alternating pattern to locate the scan points
for decoding. Grid non-uniformity checks the
extent to which the grid deviates from the ideal
grid.
GNUG - ISO15415 Grid non-uniformity grade Value for grid non-uniformity according to ISO/
IEC15415. A grid is placed over the code using
the alternating pattern to locate the scan points
for decoding. Grid non-uniformity checks the
extent to which the grid deviates from the ideal
grid.
MODV - ISO15415 Modulation value Value for modulation according to ISO/
IEC15415. Checks uniformity of the reflectance
of dark and light dots.
MODG - ISO15415 Modulation grade Grading for modulation according to ISO/
IEC15415. Checks uniformity of the reflectance
of dark and light dots.
FPDV - ISO15415 Fixed pattern damage value Value for fixed pattern damage according to ISO/
IEC15415. Checks the fundamental characteri-
stics of the code (quiet zone, finder, alternating
patterns and reference dots) for defects and cal-
culates an average.
FPDG - ISO15415 Fixed pattern damage grade Grading for fixed pattern damage according to
ISO/IEC15415. Checks the fundamental charac-
teristics of the code (quiet zone, finder, alterna-
ting patterns and reference dots) for defects and
calculates an average.
EC - ECC level Specific DMX quality value
