Chapter 5 ONLINE HELP SOPAS
LECTOR®620
94 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013778/Y269/2013-11-27
Parameters
ECCW - ECC code words Number of read code modules for Reed-Solo-
mon-Error correction
DCW - Data code words Number of code data modules
NEC - Num. ECC correctables Number of correctable code modules in case of
damage
NEE - Num. of ECC errors Number of incorrect code modules
NES - Num. of ECC erasures Number of incorrect code modules with known
position
MC - Multi Count. Indicates how often a code was read within a
reading gate (Codes are not displayed separa-
tely!)
DLSZ - Number of devices Number of connected devices
DLCS - Device list separated by comma List of connected devices separated by comma
DLBS - Device list separated by blank List of connected devices separated by blank
DN - Device number Device number alternatively parameteruzed in
field bus; default: number is identical to "Device
ID"
DIN - Increment read from device Increment read by device
SID - Symbol ID Symbol ID
More obj. related items… Description
FIX1 - Fix defined string 1 User defined string 1
FIX2 - Fix defined string 2 User defined string 2
FIX3 - Fix defined string 3 User defined string 3
TT - Reading gate duration in ms Reading gate duration in ms
OTL - Trigger length in mm Trigger length in mm
NZ - Nr. of mismatches Number of mismatches (codes which do not fulfil
the matchcode condition)
NY - Nr. of no matches Number of objects without any match
GNC - Global nr. of codes Number of codes
NVRB - Global nr. valid released codes Number of valid released codes
NC - Number of reading gates Number of reading gates
DID - Device ID Device ID
SCGR - Superordinate counter Good Read Superordinate Good Read counter; remains in
case of a new parameterization (reset via power
cycle)
SCNR - Superordinate counter No Read Superordinate No Read counter; remains in case
of a new parameterization (reset via power cycle)
DEVN - Device name Device name
APC01 - Application counter 1 Definable counter 1
APC02 - Application counter 2 Definable counter 2
APC03 - Application counter 3 Definable counter 3
APC04 - Application counter 4 Definable counter 4
APC05 - Application counter 5 Definable counter 5
APC06 - Application counter 6 Definable counter 6
APC07 - Application counter 7 Definable counter 7
APC08 - Application counter 8 Definable counter 8
More… Description
