ON – Object number Number of the current object (total number of
scanned objects)
CC – Code count Number of codes that have been read within rea-
ding gate
VCC – Number of valid codes Number of valid codes within reading gate
More code-related data… Description
IWA – Code ID Code type designated according to alignment
number (ASCII position of the code ID, i.e.,
alphabetical numbering of the code types)
IN – Increment Increment value at the start of the reading gate
FC – Focus position Reading distance setting in mm
RSD1DV – Ratio between scans and decoded
scans
Value that indicates the ratio between "S1D –
Number of scans completed on a 1D code" and
"SD1D – Number of scans completed suc-
cessfully on a 1D code"; grading for evaluating
the reading stability of 1D codes.
VTH – CS threshold for code to become valid Valid when CS ≥ VTH, i.e. number of scans =
VTH*2 (for 1D codes only)
S1D – Scans on 1D codes Number of scans completed on 1D codes
SD1D – Decoded scans on 1D codes Number of successful scans completed on 1D
codes
FCT – Full code type description Code type, detailed description
DI – Dimension Indicates whether the code is 1D or 2D
X1 – Code corner 1 X Pixel position of code corner 1X
Y1 – Code corner 1 Y Pixel position of code corner 2Y
X2 – Code corner 2 X Pixel position of code corner 2X
Y2 – Code corner 2 Y Pixel position of code corner 2Y
X3 – Code corner 3 X Pixel position of code corner 3X
Y3 – code corner 3 Y Pixel position of code corner 3Y
X4 – code corner 4 X Pixel position of code corner 4X
Y4 – code corner 4 Y Pixel position of code corner 4Y
CPX – X position relative to image origin Code center X in pixels
CPY – Y position relative to image origin Code center Y in pixels
AN2 – Tilt angle Tilt angle for 1D and 2D codes [in degrees] rela-
tive to the horizontal
MCR – Ratio between image and MC [in %] Relationship between images that have been
taken and successful multireads
X2D – X 2D Symbol size (number of modules) in X direction;
for 2D codes only
Y2D – Y 2D Symbol size (number of modules) in Y direction;
for 2D codes only
MX2 – Module X size Average module size in X direction in mm; for 2D
codes only
MY2 – Module Y size Average module size in Y direction in mm; for 2D
codes only
IV2 – Inverse (boolean) Code was read inversely
MD2 – Mirrored (boolean) Code was read as a mirror-image
Data Description
