SICK M4000 Advanced User Manual

Operating Instructions Chapter 13
M4000 Adv., Adv. A/P, Area
8010797/YT72/2016-02-19 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 119
Subject to change without notice
Technical specifications
13.2 Table of weights
13.2.1 M4000 Advanced and M4000 Advanced A/P
Number of beams Beam separation [mm] Type code Weight [g]
M40Z-0250#####
33)
1860
500
M40#-0250##### 1925
2
600 M40#-0260##### 2200
220 M40#-0322##### 1760
400 M40#-0340##### 2750
3
450 M40#-0345##### 3025
220 M40#-0422##### 2370
M40Z-0430#####
33)
3040
4
300
M40#-0430##### 3030
5 M40#-0522##### 2975
6 M40#-0622##### 3580
7 M40#-0722##### 4185
8
220
M40#-0822##### 4795
13.2.2 M4000 Passive
For number
of beams
Deflector unit Part number Type code Weight [g]
Mirror deflection 1027906 PSD01-1501 1500
2
Fibre-optic deflection 1027907 PSD01-2501 1760
4 Fibre-optic deflection 1027908 PSD02-2301 2920
13.2.3 M4000 Area 60/80
Weight [g]
Length of the monitored area
[mm]
Type code
M4000
Area 60
M4000
Area 80
300 M40#-60A###### 1290 n. u.
450 M40#-61A###### 1740 n. u.
600 M40#-62A###### 2195 2090
750 M40#-63A###### 2650 2510
900 M40#-64A###### 3100 2950
1050 M40#-65A###### 3555 3375
1200 M40#-66A###### 4010 3795
1350 M40#-67A###### 4465 4230
1500 M40#-68A###### 4915 4660
1650 M40#-69A###### 5370 5095
1800 M40#-70A###### 5825 5515
33)
M4000 Advanced A/P.
Tab.
43
:
Table of weights
M4000 Advanced and
M4000 Advanced A/P
Tab.
44
:
Table of weights
M4000 Passive
Tab.
45
:
Table of weights
M4000 Area 60/80
