SICK M4000 Advanced User Manual

Operating Instructions Chapter 13
M4000 Adv., Adv. A/P, Area
8010797/YT72/2016-02-19 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 113
Subject to change without notice
Technical specifications
13 Technical specifications
13.1 Data sheet
M4000 Advanced, M4000 Advanced A/P and M4000 Area 60/80
Minimum Typical Maximum
General system data
Type Type 4 (IEC 61496E1)
Safety Integrity Level
9)
SIL3 (IEC 61508)
SIL claim limit
9)
SILCL3 (EN 62061)
Category Category 4 (EN ISO 13849E1)
Performance Level
9)
PL e (EN ISO 13849E1)
PFHd (mean probability of a
dangerous failure per hour)
M4000 Advanced 6.6× 10
–9
M4000 Advanced A/P 6.6× 10
–9
M4000 Area 60/80 14× 10
–9
T
M
(mission time) 20 years (EN ISO 13849)
Safe state in case of an error At least one OSSD is in the LOW state
Number of beams, type-dependent
M4000 Advanced 2 12
M4000 Advanced A/P 2 4
Length of the monitored area,
depending on type
M4000 Area 60 300 mm 1800 mm
M4000 Area 80 600 mm 1800 mm
Beam separation, type-dependent
M4000 Advanced 120 mm 600 mm
M4000 Advanced A/P 500 mm and
300 mm
M4000 Area 60/80 50 mm 57 mm
Resolution, depending on type
M4000 Area 60/80 60 mm 80 mm
9)
For detailed information on the safety design of your machine/system, please contact your local SICK
representative.
Tab.
42
:
Data sheet
M4000
Advanced, M4000
Advanced A/P and M4000
Area 60/80

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
