SICK M4000 Advanced User Manual

Operating Instructions Chapter 14
M4000 Adv., Adv. A/P, Area
8010797/YT72/2016-02-19 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 135
Subject to change without notice
Ordering information
M4000 Area 80
with M26 Hirschmann plug
Type code Type code Length of the
monitored area
[mm]
 Sender  Receiver
600 M40S-62A105AA0 M40E-62A105RA0
750 M40S-63A105AA0 M40E-63A105RA0
900 M40S-64A105AA0 M40E-64A105RA0
1050 M40S-65A105AA0 M40E-65A105RA0
1200 M40S-66A105AA0 M40E-66A105RA0
1350 M40S-67A105AA0 M40E-67A105RA0
1500 M40S-68A105AA0 M40E-68A105RA0
1650 M40S-69A105AA0 M40E-69A105RA0
1800 M40S-70A105AA0 M40E-70A105RA0
14.3.3 Default delivery status
 The pre-setting for the device configuration is termed the default delivery status. You
can accept or change these pre-settings (see chapter 10 “Configuration” on page 103).
 The default delivery status is only applicable for the device types listed in chap-
ter 14.3.2 “Type code” on page 134ff.
Configuration Function
 Sender  Receiver
Beam coding Non-coded Non-coded
Sender test Deactivated –
Restart interlock – Internal
External device monitoring (EDM) – Activated
Scanning range
M4000 Area 60 – 0.5-6 m
M4000 Area 80 – 0.5-20 m
Application diagnostic output (ADO) – Contamination
Tab.
62
:
Type codes
M4000 Area 80 with
M26 plug
Notes
Tab.
63
:
Default delivery
status M4000 Area 60/80

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
