Ordering information
14.1.3 Default delivery status
The pre-setting for the device configuration is termed the default delivery status. You
can accept or change these pre-settings (see chapter 10 “Configuration” on page 103).
The default delivery status is only applicable for the device types listed in chap-
ter 14.1.2 “Type code” on page 130ff.
Configuration Function
Sender Receiver
Beam coding Non-coded Non-coded
Sender test Deactivated –
Restart interlock – Internal
External device monitoring (EDM) – Activated
Scanning range – 0.5-20 m
Application diagnostic output (ADO) – Contamination
14.2 M4000 Advanced A/P
14.2.1 Delivery
M4000 Advanced A/P M4000 Passive
sender/receiver unit
4 sliding nuts for side bracket
label “Important Information”
operating instructions on CDEROM
CDS (Configuration & Diagnostic
Software) on CDEROM
deflector unit
4 sliding nuts for side bracket
14.2.2 Type code
M4000 Advanced A/P
with M26 Hirschmann plug and
M12× 5 socket
Type code Part number Type code Number of
beams
Beam separation
[mm]
M4000 Advanced A/P M4000 Passive
M40Z-025003RB0 1027906 PSD01-1501
37)
2 500
M40Z-025003TB0 1027907 PSD01-2501
38)
4 300 M40Z-043003TB0 1027908 PSD02-2301
38)
37)
With mirror deflection (max. effective scanning range 7.5 m).
38)
With fibre-optic deflection (max. effective scanning range 4.5 m).
Notes
status M4000 Advanced
M4000 Advanced A/P
M4000 Advanced A/P with
M26 plug
