Configurable functions
5.4.3 Scanning range of the M4000 Advanced A/P
With the M4000 Advanced A/P multiple light beam safety device you must differentiate
between the scanning range to be configured and the maximum effective scanning
r
ange.
You must configure the scanning range to be configured to suit the deflector unit used
(mirror deflection or fibre-optic deflection) (see Tab. 15).
Deflector unit used Scanning range to be configured
Mirror deflection
 M4000 Passive with mirror deflection
or
 two deflector mirrors PSK45 (see section 13.3.10
“Deflector mirror PSK45” on page 129)
or
 one mirror column (part number: 1041917, see
section 14.5 “Deflector mirrors and mirror
columns” on page 138)
Low scanning range
Fibre-optic deflection
 M4000 Passive with fibre-optic deflection
High scanning range
Device symbol M4000 Advanced (A/P), context menu Open device window, parameter
node General.
The maximum effective scanning range is dependent here on the number of deflections
between the M4000 Advanced A/P and the M4000 Passive and the number of additional
front screens used (see Tab. 16).
Maximum effective scanning range Number
of
deflections
2)
Number of
additional
front screens
Mirror
deflection
Fibre-optic
deflection
Without 7.5 m 4.5 m
1 6.3 m 3.8 m
None
2 5.1 m 3.5 m
Without 6.0 m Not
recommended
1 5.1 m Not
recommended
1
2 4.3 m Not
recommended
2)
Between M4000 Advanced A/P and M4000 Passive.
Tab.
15
:
Scanning range of
the M4000 Advanced A/P to
be configured dependent of
the deflector unit used

Tab.
16
:
Maximum effective
scanning range of the
M4000 Advanced A/P as a
function of the number of
deflections and the number
of additional front screens
