Ordering information
14.7 Accessories
Part Part number
Mounting kits
Mounting kit 1: mounting bracket rigid, 4 pcs. 7021352
Mounting kit 2: mounting bracket pivoting, 4 pcs. 2017751
Mounting kit 6: side bracket pivoting, 4 pcs. 2019506
M
ounting kit 12: swivelEmount bracket, pivoting, 4 pcs 2030510
Omega bracket for M4000, 4 pieces 2044846
M4000 system connection
Hirschmann cable socket M26× 11 + FE, crimp contacts, straight 6020757
Hirschmann cable socket M26× 11 + FE, crimp contacts, angled 6020758
Terminal with 182 _ resistance for pin 9 and 10 on the system
connection (see page 83)
2027227
Connecting cable for M4000 with Hirschmann cable socket
M26× 11 + FE:
Socket straight, stripped, 2.5 m 2022544
Socket straight, stripped, 5 m 2022545
Socket straight, stripped, 7.5 m 2022546
Socket straight, stripped, 10 m 2022547
Socket straight, stripped, 15 m 2022548
Socket straight, stripped, 20 m 2022549
Socket straight, stripped, 30 m 2022550
Connecting cable for M4000 with Hirschmann cable socket
M26× 11 + FE (without EFI: pin 9 and 10 not connected):
Socket straight, stripped, 5 m 2046888
Socket straight, stripped, 10 m 2046889
Socket straight, stripped, 20 m 2046890
M4000 extension connection
Connection cable for M4000 Advanced with 5Epin M12 plug and
UE403
Wire cross-section 0.34 mm², 5Epin M12 plug, 5Epin M12 socket,
PUR halogen-free
Plug straight/socket straight, 0.6 m 6025930
Plug straight/socket straight, 1.0 m 6029280
Plug straight/socket straight, 1.5 m 6029281
Plug straight/socket straight, 2.0 m 6025931
Plug straight/socket straight, 5.0 m 6029282
Safety relay
UE403 (UE403-A0930) 1026287
accessories
