Chapter 15 Operating Instructions
M4000 Adv., Adv. A/P, Area
142 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/YT72/2016-02-19
Subject to change without notice
Annex
15.2 Checklist for the manufacturer
Κ
Checklist for the manufacturer/installer for the installation of
electro-sensitive protective equipment (ESPE)
Details about the points listed below must be present at least during initial commissioning — they are, however,
dependent on the respective application, the specifications of which are to be controlled by the manufacturer/installer.
This checklist should be retained and kept with the machine documentation to serve as reference during recurring
tests.
1. Have the safety rules and regulations been observed in compliance with the
directives/standards applicable to the machine?
Yes No
2. Are the applied directives and standards listed in the declaration of conformity? Yes No
3. Does the protective device comply with the required PL/SIL claim limit and PFHd in accordance
with EN ISO 13849-1/EN 62061 and the required type in accordance with IEC 61496-1?
Yes No
4. Is access to the hazardous area/hazardous point only possible through the light path/the
protective field of the ESPE?
Yes No
5. Have appropriate measures been taken to protect (mechanical protection) or monitor (protec-
tive devices) any persons or objects in the hazardous area when protecting a hazardous area
or hazardous point, and have these devices been secured or locked to prevent their removal?
Yes No
6. Are additional mechanical protective measures fitted and secured against manipulation which
prevent reaching under, over or around the ESPE?
Yes No
7. Has the maximum stopping and/or stopping/run-down time of the machine been measured,
specified and documented (at the machine and/or in the machine documentation)?
Yes No
8. Has the ESPE been mounted such that the required minimum distance from the nearest
hazardous point has been achieved?
Yes No
9. Are the ESPE devices correctly mounted and secured against manipulation after adjustment? Yes No
10. Are the required protective measures against electric shock in effect (protection class)? Yes No
11. Is the control switch for resetting the protective equipment (ESPE) or restarting the machine
present and correctly installed?
Yes No
12. Are the outputs of the ESPE (OSSD) integrated according to required PL/SILCL compliant with
EN ISO 13849-1/EN 62061 and does the integration correspond to the comply with the circuit
diagrams?
Yes No
13. Has the protective function been checked in compliance with the test notes of this
documentation?
Yes No
14. Are the specified protective functions effective at every operating mode that can be set? Yes No
15. Are the switching elements activated by the ESPE, e.g. contactors, valves, monitored? Yes No
16. Is the ESPE effective over the entire period of the dangerous state? Yes No
17. Is a dangerous state halted when the ESPE is switched on or off, the operating modes are
changed over, or when switching over to another protective device?
Yes No
18. Has the information label for the daily check been attached so that it is easily visible for the
operator?
Yes No
This checklist does not replace the initial commissioning, nor the regular inspection by qualified safety personnel.
