14.5 Deflector mirrors and mirror columns
Description Part number
Deflector mirror PNS75-008, including mounting kit 1026647
Deflector mirror PSK45, including mounting kit, not suitable for
column mounting
5306053
Mirror column, fully assembled with mirrors
Suitable for M40#-0250#####, 2Ebeam, 500 mm beam separation
1040619
M
irror column, fully assembled with mirrors
Suitable for M40#-0260#####, 2Ebeam, 600 mm beam separation
1
040620
Mirror column, fully assembled with mirrors
Suitable for M40#-0340#####, 3Ebeam, 400 mm beam separation
1040625
Mirror column, fully assembled with mirrors
Suitable for M40#-0345#####, 3Ebeam, 450 mm beam separation
1040624
Mirror column, fully assembled with mirrors
Suitable for M40#-0430#####, 4Ebeam, 300 mm beam separation
1040626
Mirror column, fully assembled with mirrors (45°)
Suitable for M40Z-02500#### and M40Z-02501####,
2Ebeam, 500 mm beam separation
1041917
Adjusting plate
Suitable for mirror and device columns
4031053
Mirror columns affect the scanning range of the system. On this subject see section 5.4
“Scanning range” on page 42ff.
14.6 Device columns
Description Part number
Stable device columns with 2 exterior mounting grooves for safety
light curtains and multiple light beam safety devices
Column height 985 mm 2045490
Column height 1165 mm 2045641
Column height 1265 mm 2045642
Column height 1720 mm 2045643
Column height 2020 mm 2045644
Column height 2250 mm 2045645
Column height 2400 mm 2045646
Adjusting plate
Suitable for mirror and device columns
4031053
Omega bracket for device columns, long, 2 pieces 2045736
Steel plug for floor fastening 5308961
Tab.
65
:
Part numbers
deflector mirrors and mirror
columns
Note
Tab.
66
:
Part numbers
device columns

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
