Ordering information
M4000 Advanced A/P
with M26 Hirschmann plug,
M12× 5 socket and
end cap with integrated LED
Type code Part number Type code Number of
beams
Beam separation
[mm]
  M4000 Advanced A/P M4000 Passive
M40Z-025023RB0 1027906 PSD01-1501
39)
2 500
M40Z-025023TB0 1027907 PSD01-2501
40)
4 300 M40Z-043023TB0 1027908 PSD02-2301
4
0)
14.2.3 Default delivery status
 The pre-setting for the device configuration is termed the default delivery status. You
can accept or change these pre-settings (see chapter 10 “Configuration” on page 103).
 The default delivery status is only applicable for the device types listed in chap-
ter 14.2.2 “Type code” on page 132ff.
Configuration Function
  M4000 Advanced A/P
Beam coding Non-coded
Restart interlock Internal
External device monitoring (EDM) Activated
Scanning range Preconfigured depending on type
Application diagnostic output (ADO) Contamination
39)
With mirror deflection (max. effective scanning range 7.5 m).
40)
With fibre-optic deflection (max. effective scanning range 4.5 m).
Tab.
58
:
Type codes
M4000
Advanced A/P with M26 plug
and end cap with integrated
LED
Notes
Tab.
59
:
Default delivery
status M4000 Advanced A/P

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
