Operating Instructions Chapter 5
M4000 Adv., Adv. A/P, Area
8010797/YT72/2016-02-19 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 43
Subject to change without notice
Configurable functions
5.4.1 Scanning range of the M4000 Advanced
You can set the M4000 Advanced multiple light beam safety device to two different scan-
ning ranges. The effective scanning range is dependent here upon the dimension of the
l
ight path between sender and receiver and the number of deflector mirrors and additional
front screens used. You will find the necessary scanning ranges and the resulting setting
in Tab. 14.
The following scanning ranges are available:
low scanning range (0.5-20 m)
high scanning range (9-70 m)
Device symbol M4000 Advanced (receiver), context menu Open device window, para-
meter node General.
Number of
deflections
per beam
Number of
additional
front screens
M4000 Advanced
with short
scanning range
M4000 Advanced
with long
scanning range
Without 0.5-20.0 m 9.0-70.0 m
1 0.5-18.4 m 9.0-64.4 m
None
2 0.5-16.9 m 9.0-59.2 m
Without 0.5-18.0 m 9.0-63.0 m
1 0.5-16.5 m 9.0-57.9 m
1
2 0.5-15.1 m 9.0-53.2 m
Without 0.5-16.0 m 9.0-56.0 m
1 0.5-14.7 m 9.0-51.5 m
2
2 0.5-13.5 m 9.0-47.3 m
Without 0.5-14.3 m 9.0-50.0 m
1 0.5-13.1 m 9.0-46.0 m
3
2 0.5-12.0 m 9.0-42.3 m
Without 0.5-12.8 m 9.0-45.0 m
1 0.5-11.7 m 9.0-41.4 m
4
2 0.5-10.7 m 9.0-38.0 m
5.4.2 Scanning range of the M4000 Advanced Curtain system
Information on the scanning range of the M4000 Advanced Curtain-system can be found
in the corresponding Addendum Operating Instructions “M4000 Standard Curtain and
M4000 Advanced Curtain” in the “Scanning Range” section.
the M4000 Advanced as a
function of the number of
deflections per beam and the
additional front screens
