Configurable muting functions
6.10 Combinable muting functions and facilities for
connecting
Up to three different muting functions can be combined for any application. Tab. 28 shows
t
he possible combinations (A to Q).
Possible combinations Function that
can be
configured
A B
4)
C
4)
D E
4)
F G H I
4)
J K L M
4)
N
4)
O P
4)
Q
Reset       
Reset/override
(combined)

  
Override      
Additional
signal C1

      
Belt stop        
There are different connection options for the signals:
 The signals for Reset, Reset/Override (combined)
5)
, Additional signal C1 and Belt stop
can be optionally connected to M4000 multiple light beam safety device or to the
UE403 or sens:Control device.
 The Override signal can only be connected to the UE403 or sens:Control device.
 Each signal must only be connected once.
The used connections and functions are configured with the help of the CDS. Device
symbol M4000 Advanced (receiver) or M4000 Advanced (A/P), context menu Open
device window, parameter node I/O configuration. Invalid combinations are prevented by
the software.
4)
This combination option is not available if an IP 67 Remote-I/O-controller, e.g. UE4455 is used since pins 5
and 11 of M4000 cannot be used in an IP 67 environment.
5)
It is only possible to connect Reset/Override (combined) on the M4000 in conjunction with an UE403 or
sens:Control device.
Tab.
28
:
Combinable muting
functions

