SICK M4000 Advanced User Manual

Chapter 14 Operating Instructions
M4000 Adv., Adv. A/P, Area
140 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/YT72/2016-02-19
Subject to change without notice
Ordering information
Part Part number
Muting lamps
for connection to UE403
Version with incandescent lamp, incl. 2 m connecting cable with
M12 plug, mounting bracket and mounting kit
2033116
Version with incandescent lamp, incl. 10 m connecting cable with
M12 plug, mounting bracket
2033117
Version with LED, incl. 2 m connecting cable with M12 plug,
mounting bracket and mounting kit
2033118
Version with LED, incl. 10 m connecting cable with M12 plug,
mounting bracket
2033119
Muting mechanism components
1 × round steel arm 400 mm
For PU3H column profile and M4000 device profile
incl. 1 × universal bracket 2045506
incl. 2 × universal brackets 2045507
incl. 1 × universal bracket with reflector P250 fitted 2045513
incl. 2 × universal brackets with reflectors P250 fitted 2045512
incl. 1 × universal bracket with sensor WL280P132 fitted and 2 m
connecting cable with M12 plug
2045729
incl. 2 × universal brackets with sensors WL280P132 fitted and
2 m connecting cable with M12 plug
2045730
2 × round steel arm 400 mm
For PU3H column profile and M4000 device profile
incl. 4 × universal brackets (for exit monitoring) 2045508
incl. 2 × universal brackets with sensors WL280P132 mounted and
2 m connection cable with M12 plug and 2 × universal brackets
with reflectors P250 mounted (for exit monitoring)
2060157
Connection cable for PC
For the connection between PC and M4000 or UE403 (2.0 m) 6021195
External laser alignment aid
AR60 1015741
Adapter for M4000 housing 4040006
Accessories included in a standard delivery
CDS (Configuration & Diagnostic Software) on CDEROM incl. Online
documentation and operating instructions in all available languages
2032314
Sliding nuts for mounting bracket/side bracket, 4 pcs 2017550
Alignment template for integrated laser alignment aid
41)
4040263
41)
Only with devices with integrated laser alignment aid.

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
