Chapter 13 Operating Instructions
M4000 Adv., Adv. A/P, Area
114 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/YT72/2016-02-19
Subject to change without notice
Technical specifications
Minimum Typical Maximum
Scanning range, configurable
M4000 Advanced,
M4000 Area 80
Low scanning range 0.5 … 20 m
High scanning range 9 … 70 m 9 … 90 m
10)
M4000 Area 60
Low scanning range 0 … 6 m
High scanning range 5 … 19 m 5 … 21 m
Scanning range
1
1)
M4000 Advanced A/P
With mirror deflection 0.5 m 7.5 m
With fibre-optic deflection 0.5 m 4.5 m
Beam diameter
M4000 Advanced,
M4000 Advanced A/P and
M4000 Area 80
23 mm
M4000 Area 60 13 mm
Protection class
12)
III (EN 50178)
Enclosure rating IP 65 (EN 60529)
Supply voltage V
S
at device
13)
19.2 V 24 V 28.8 V
Residual ripple
14)
±10%
Synchronisation
15)
Optical, without separate synchronisation
Power-up delay of sender and
receiver before ready
10 s
Sender
Test input
Input voltage
16)
HIGH (active) 11 V 24 V 30 V
Input current HIGH 7 mA 10 mA 20 mA
Switching voltage LOW
(inactive)
–30 V 0 V 5 V
Input current LOW
16)
–3.5 mA 0 mA 0.5 mA
Response time to test Depending on the number of beams, maximum
150 ms
Wavelength of sender
15)
Near infrared (NIR), invisible
17)
10)
On the utilisation of this protective field width, it must be expected the orange LED will illuminate (cleaning or
realignment required). The system then only has a reserve of 30%.
11)
The scanning range of the M4000 Advanced A/P device must be configured to suit the deflection used (see
section 5.4.3 “Scanning range of the M4000 Advanced A/P” on page 44).
12)
Safety extra-low voltage SELV/PELV.
13)
The external voltage supply must be capable of buffering brief mains voltage failures of 20 ms as specified in
EN 60204-1. Suitable power supplies are available as accessories from SICK (Siemens type series 6 EP 1).
14)
Within the limits of V
S
.
15)
Only with Active/Active systems.
16)
As per IEC 61131-2.
17)
For the exact value see www.sick.com.
