SICK M4000 Advanced User Manual

Operating Instructions Chapter 13
M4000 Adv., Adv. A/P, Area
8010797/YT72/2016-02-19 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 121
Subject to change without notice
Technical specifications
M4000 Advanced
Number of
beams
Beam separation S1
[mm]
Dimension L1
[mm]
Dimension L2
[mm]
500 643 672
2
600 743 772
220 583 612
400 943 972
3
450 1043 1072
220 803 832
4
300 1043 1072
5 1023 1052
6 1243 1272
7 1462 1491
8
220
1682 1711
M4000 Advanced A/P
Number of
beams
Beam separation S1
[mm]
Dimension L1
[mm]
Dimension L2
[mm]
2 500 643 672
4 300 1043 1072
If you use the M4000 Advanced (or the M4000 Advanced A/P) with optional end cap with
integrated LED, the dimension L2 of the receiver increases by 25 mm.
Tab.
46
:
Dimensions of the
M4000 Advanced or the
M4000 Advanced A/P
dependent on the number of
beams
Note

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
