How to make the alignment templates:
 Copy this page.
 Cut the copied template along the edge and at the line marked.
 Cut out the two targets on the laser alignment aid and the circular opening for the beam
optics.
Fig. 81: Alignment templates
copying master
Laser alignment aid
target
80
mm
80
mm
Cut line
Alignment template for sender
Alignment template for mirrors
Laser alignment aid
target
Circular opening for
beam optics
