10 TECHNICAL SPECIFICATIONS
8020065-ZSP4/2017-08-10|SICK
OPERATING INSTRUCTIONS | Master Data Analyzer
Subject to change without notice
116
10 Technical specifications
10.1 Data sheets
10.1.1 System data sheet
Measurement field (L x W x H)
MDA650 / MDA650 Image
MDA800 / MDA800 Image
650 mm x 600 mm x 600 mm
800 mm x 600 mm x 600 mm
Measurement results
Length, width, height, volume, weight
Measurement accuracy
± 5 mm
Measurement sensor
Infrared light
Measuring direction
On both sides
Bar codes
1D, 2D, stacked codes
Start and end point of the measurement
Specified by object contours
Object properties
Remission (influence of object surface) does not
effect the measurement result. The system can
also measure transparent, reflective, and very
dark objects
Object geometry
Any (cubic, round, irregular)
Minimum object size (L x W x H)
10 mm x 10 mm x 5 mm
Maximum object size (L x W x H)
MDA650 / MDA650 Image
MDA800 / MDA800 Image
650 mm x 600 mm x 600 mm
800 mm x 600 mm x 600 mm
Object rotation
Omni
Maximum object weight
Up to 30 kg
Minimum object weight
20 g
Accuracy of the electronic scales
0.005 kg (up to 15 kg)
0.01 kg (up to 30 kg)
Supply voltage
AC 100 ... 264 V / 50 ... 60 Hz
Ambient operating temperature
0 °C ... +40 °C
Dimensions (L x W x H)
MDA650 / MDA650 Image
MDA800 / MDA800 Image
1,210 mm x 900 mm x 900 mm
1,360 mm x 900 mm x 900 mm
Weight
65 kg
Tab. 26: Data sheet for the Master Data Analyzer
10.1.2 Data sheet for the IDM26x hand-held scanner (wired)
Features
Scanner design
2D code hand-held scanner, RS-232 TTL spiral cable
Light source
Visible red light (630 nm)
Reading distance
30 mm ... 380 mm
Scanning frequency
60 Hz
Reading width
200 mm at a reading distance of 200 mm
Code resolution
≥ 0.08 mm (code 39)
≥ 0.18 mm (Data Matrix code)
Performance
Supported code types
1D, 2D, stacked
Interfaces
Data interface
RS-232 TTL (to the MSC800 controller)
Optical indicators
1 LED for read confirmation
1 LED for operating status
Acoustic indicators
Beeper for read confirmation
Vibration
Yes
Mechanics/electronics
Supply voltage
DC 5 V ± 5 %
Housing color
Blue, gray
Enclosure rating
IP 65
Weight
Approx. 200 g, without cables
Dimensions
104 mm x 76 mm x 176 mm
