COMMISSIONING 6
8020065-ZLP4/2017-08-10|SICK
Subject to change without notice
OPERATING INSTRUCTIONS | Master Data Analyzer
6.4.2 Storing connection data for the customer server
In the second step, store the FTP connection data for the customer server to which the
measurement results should be transmitted. The measurement results with image data
are stored on the FTP server in freely definable directories. Access to the FTP server is
normally protected with a username and password.
▸
In the configuration interface’s tree structure, select the function Parameter
Application parameter.
The FTP protocol relevant for data transmission is pre-selected as standard under the
Data Host Output field.
This setting must not be changed.
The following parameters must be adjusted to the customer’s requirements.
Data host FTP server
address
Enter the IP address for the server to which the measurement results
should be transferred.
Add the port that should be used to connect to the server.
username
Data host FTP
Enter the FTP username and password which are used to access the
FTP server.
upload path files
Data host FTP
upload path images
Enter the directories that should be used to store the measurement
results with the corresponding image files (only when using the IP
camera) on the FTP server. Measurement data and image files can be
stored in different directories.
As the default setting, the directories SICKTransfer/dimensions and
SICKTransfer/itemPictures are suggested under the FTP root directory.
▸ Change these suggestions accordingly.
Notes
Make sure that the directories you enter here actually exist on the
FTP server and that the specified FTP user has write access for these
directories.
If you do not enter any information under these fields, measurement
data and images are stored directly in the FTP server’s root directory.
All other parameters must be accepted with their default value.
