OPERATING INSTRUCTIONS | Master Data Analyzer
Ambient data
Shock resistance
50 drop tests onto concrete from a height of 2 m
Ambient operating temperature
–20 °C …+50 °C
Storage temperature
–40 °C… +70 °C
Permissible relative humidity
95 %, non-condensing
Ambient light immunity
100,000 lx
Tab. 27: Data sheet for the IDM26x hand-held scanner (wired)
10.1.3 IP camera Axis M3005-V
Camera type
Axis M3005-V, fixed alignment dome network camera
Mounting type
Fixed alignment
Triggering
Upon measurement of the front edge of the object
Resolution in pixels
800 x 800 ... 1920 x 1080
Supply voltage
Power-over-Ethernet (PoE)
Data transmission
FTP (separate interface)
Tab. 28: Data sheet for the dome network camera Axis M3005-V
10.1.4 WLAN Ethernet port adapter FL WLAN EPA
Type
FL WLAN EPA -2692791 (Phoenix Contact)
Name
Wireless LAN
Wireless standard
IEEE 802.11
g;b;n
Aerial connection type
Internal
Frequency range
2.402 GHz ... 2.48 GHz (ISM band)
Frequency band
2.4 GHz
Transmitting power
Max. 20 dBm (EIRP)
Number of wireless interfaces
1 IEEE 802.11 b/g/n
Tab. 29: WLAN Ethernet port adapter FL WLAN EPA
