3 SYSTEM DESCRIPTION
8020065-ZSP4/2017-08-10|SICK
OPERATING INSTRUCTIONS | Master Data Analyzer
Subject to change without notice
20
3 System description
This chapter provides information on the special properties of the DWS system. It describes
the design and operating principle of the system solution.
3.1 Scope of delivery
The Master Data Analyzer is available in two different monitoring lengths, each of which is
available with and without an IP camera.
System variants
Part no.
Description
1079161
Master Data Analyzer MDA650 with a monitoring length of 650 mm
1079162
Master Data Analyzer MDA800 with a monitoring length of 800 mm
1079163
Master Data Analyzer MDA650 Image with a monitoring length of 650 mm
and a fixed IP camera
1079164
Master Data Analyzer MDA800 Image with a monitoring length of 800 mm
and a fixed IP camera
Tab. 3: System variants
Optional accessories
Part no.
Description
2087193
WLAN module with mounting kit for mobile applications
2087216
Sliding table
2087217
Sliding table with built-in rechargeable battery
6062161
Power supply unit
Tab. 4: Optional accessories
On request, the Master Data Analyzer is available with scales that can be verified.
Verification takes place at the factory.
Operating the scales in LFT mode (Legal for Trade mode) is useful if the logged data are
used for invoicing purposes or if certified accuracy must be ensured.
Note
