SYSTEM DESCRIPTION 3
31
8020065-ZLP4/2017-08-10|SICK
Subject to change without notice
OPERATING INSTRUCTIONS | Master Data Analyzer
3.4 Project planning
System requirements
The following conditions must be met to operate the Master Data Analyzer:
• Supply voltage: AC 100 to 264 V/50 to 60 Hz
• Ethernet connection of WLAN access point for forwarding the measurement results
to the customer’s system
Requirements for the operation site
• Closed room
• Flat and firm surface
• Low-vibration environment
• Protected from wind and free of drafts
• Well-lit
• Clean and dry
• Room temperature below 40 °C
Regardless of the space requirements of the MDA, there must be enough space at the
operation site for the following activities:
• Operating the system
• Cleaning, repair, and service
Ethernet connection requirements
In the operating mode without bar code scanning, a permanent Ethernet connection
must be in place otherwise the measurement results will not be able to be assigned to the
bar code in the customer’s system.
Object requirements
Dimension
Explanation
Minimum object size (L x W x H)
10 mm x 10 mm x 5 mm
Maximum object size (L x W x H)
MDA650 / MDA650 Image
MDA800 / MDA800 Image
650 mm x 600 mm x 600 mm
800 mm x 600 mm x 600 mm
Object rotation
Omni
Minimum object weight
20 g
Maximum object weight
30,000 g
Singulation
Yes
Tab. 5: Conveying system and object requirements
If the object moves suddenly or vibrates on the MDA during the measurement process,
the accuracy may be reduced and less data may be recorded by the system.
