OPERATING INSTRUCTIONS | Master Data Analyzer
3.5.2 Status indicators – Hand-held scanner (only in operating mode with bar code scanning)
Optical indicators
The wired hand-held scanner has an LED to display the operational and reading status.
Fig. 21: Status indicators – Hand-held scanner
LED indicator
Description

Blue
LED is permanently blue: Supply voltage on
 Green
LED flashes green once: The bar code has been scanned successfully
Tab. 8: Status indicators – Hand-held scanner
Further indicators
Indicator
Description
Beeper
1 beep following successful scan.
Vibration
Vibration following successful scan.
