6 COMMISSIONING
8020065-ZSP4/2017-08-10|SICK
OPERATING INSTRUCTIONS | Master Data Analyzer
Subject to change without notice
6 Commissioning
In principle, the Master Data Analyzer is ready for operation when it is connected to
the voltage supply. However, a small number of settings have to be adjusted first.
The IP address and exchange protocol must be set up in order to transmit the
measurement results via the data interface. The MDA’s display is not used to do this.
Instead, a configuration PC connected to the MDA via Ethernet is used. The SOPAS
configuration software must be installed on the configuration PC.
Do not commission without testing by qualified safety personnel
Before you commission the Master Data Analyzer for the first time, you must have it
checked and approved by qualified safety personnel.
Measures
▸
Observe the notes provided in chapter 2 Safety.
6.1 Starting the MDA
6.1.1 Starting up the MDA
Connect the voltage supply.
▸
Insert the male connector on the connecting cable into the socket.
All system components of the MDA system are started up and checked for operational
readiness in a self-test.
• The start-up process lasts approx. 30 s.
• The IP camera (only MDA650 Image/MDA 800 Image) is ready for operation after
approx. 120 seconds.
During the start-up phase, a window with a progress display appears on the touchscreen.
This visualizes the progress of the start-up phase.
6.1.2 Checking operational readiness
Check that the device is working properly.
Displaying operational readiness
The status indicator LED lights up blue permanently.
The green LED lights up on the sender and the receiver.
The display shows the measurement screen once it has started up.
(only MDA650/
The status LED lights up green.
The PWR LED lights up green.
Tab. 16: Checking operational readiness
Note
