SICK Master Data Analyzer User Manual

SAFETY 2
17
8020065-ZLP4/2017-08-10|SICK
Subject to change without notice
OPERATING INSTRUCTIONS | Master Data Analyzer
WARNING
Risk of injury caused by accidental movement of the measurement gantry
Whenever work is performed on the housing interior, there is a risk of crushing if the
measurement gantry moves accidentally.
There is also a risk of damage to the wire draw encoder.
Measures
▸
Use cable ties to secure the handles of the measurement gantry so that it does not
move accidentally during maintenance and repair work.
NOTE
Claims under the warranty rendered void
If the device is opened, any warranty claims against SICK AG will be void.
Measure
▸
Do not open the device housing.
2.4.5 Protective devices
The Master Data Analyzer has been built in a way that allows for safe operation.
Protective devices reduce potential risks to people and the device to the maximum
possible extent.
Fig. 1: Protective devices
• Four handles (1) make it easier to unpack and lift the MDA in line with ergonomic
principles.
• Handles (2) allow the measurement gantry to be moved safely over the object to be
measured.
• Cover plates (3) protect cables and electronic components.
