MC55_ATC_V04.00 Page 170 of 475 3/17/06

Confidential / Released

Two byte location area code in hexadecimal format (e.g. "00C3" equals 193 in decimal).

Two byte cell ID in hexadecimal format.

Example

<lac>

(str)

<ci>

(str)

AT+CREG=2

Activates extended URC mode.

AT+COPS=0

Forces ME to automatically search network operator.

+CREG: 2

URC reports that ME is currently searching.

+CREG: 1,"0145","291A"

URC reports that operator has been found.
