12.3 AT+FBADMUL Error Threshold Multiplier

This command defines the "Copy-Quality-OK" multiplier. The number of lines received with a bad pixel count is

multiplied by this number. If the result exceeds the total number of lines on the page the error rate is considered

too high. A threshold multiplier value of 20 corresponds to a 5 per cent error rate. A value of 0 implies that error

checking is not present or disabled.

Syntax

Parameter Description

0...20

(P)

...255

Note

• Used for Fax Class 2 only.

Read Command

AT+FBADMUL?

Response(s)

Write Command

AT+FBADMUL=<badmul>

Response(s)

If error is related to ME functionality:

ERROR

Reference(s) PIN ASC0 ASC1 MUX1 MUX2 MUX3 Charge  Last

EIA PN-2388 ! % ! % ! ! ! ! !

(num)
