12. FAX Commands
This chapter describes the AT commands used for fax communications.
If the ME is acting as a fax modem for a PC based fax application (e.g. "WinFax") it is necessary to select the
proper Service Class (Fax Class) provided by the ME. The ME reports its Service Class capabilities, i.e. the cur-
rent setting and the range of services available. This is provided by the AT+FCLASS command.
Service Classes supported by the ME:
The following AT commands are dummy commands:
AT+FAA Auto Answer mode
AT+FECM Error Correction Mode control
AT+FLNFC Page Length format conversion
AT+FLPL Indicate document available for polling
AT+FMINSP Minimum Phase C speed
AT+FRBC Phase C data receive byte count
AT+FREL Phase C received EOL alignment
AT+FSPL Enable polling
AT+FTBC Phase C data transmit byte count
AT+FWDFC Page width format conversion
Invoking these commands will not cause ERROR result codes, but these commands have no functionality.
12.1 FAX parameters
Below you can find a summary of parameters used by the fax-specific AT commands and responses described
in this chapter. Please note that parameter <mod> is dedicated to Fax Class 1 only. All other parameters listed
below are for Fax Class 2 only.
Parameter Description
Modulation scheme
To find out which value is actually supported by <mod> use the test commands while the ME is off-hook.
3 V21 Ch2 - 300 bps
24 V.27ter - 2400 bps
48 V.27ter - 7200 bps
72 V.29 - 7200 bps
96 V.29 - 9600 bps
Binary File Transfer Mode
[0] Disable BFT
1 Enable BFT
AT+FCLASS Parameter Service class Reference, Standard
0 Data modem e.g. TIA/EIA-602 or ITU V.250
1 Service Class 1 EIA/TIA-578-A
2 Manufacturer specific This document and EIA PN-2388
(draft)
<mod>
(num)
<bf>
(num)
