2.2.1 AT&V responses
The following tables show four different kinds of responses depending on whether or not the PIN is entered and
whether or not the Multiplex mode is enabled (see AT+CMUX).
Table 2.1: Current configuration on ASC0 / MUX channel 1 (example)
Table 2.2: Current configuration on ASC1 and MUX channels 2 and 3 (example)
PIN authentication done No PIN authentication
ACTIVE PROFILE:
E1 Q0 V1 X4 &C1 &D2 &S0 \Q0
S0:000 S3:013 S4:010 S5:008 S6:000 S7:060 S8:000
S10:002 S18:000
+CBST: 7,0,1
+CRLP: 61,61,78,6
+CR: 0
+FCLASS: 0
+CRC: 0
+CMGF: 1
+CSDH: 0
+CNMI: 0,0,0,0,1
+ILRR: 0
+IPR: 57600
+CMEE: 2
^SMGO: 0,0
+CSMS: 0,1,1,1
^SACM: 0,"000000","000000"
^SLCC: 0
^SCKS: 0,1
+CREG: 0,1
+CLIP: 0,2
+CAOC: 0
+COPS: 0,0,"operator"
+CGSMS: 3
OK
ACTIVE PROFILE:
E1 Q0 V1 X4 &C1 &D2 &S0 \Q0
S0:000 S3:013 S4:010 S5:008 S6:000 S7:060 S8:000
S10:002 S18:000
+CBST: 7,0,1
+CRLP: 61,61,78,6
+CR: 0
+FCLASS: 0
+ILRR: 0
+IPR: 57600
+CMEE: 2
^SCKS: 0,1
OK
PIN authentication done No PIN authentication
ACTIVE PROFILE:
E1 Q0 V1 X4 &C1 &D0 &S0 \Q0
S0:000 S3:013 S4:010 S5:008
+CR: 0
+CRC: 0
+CMGF: 1
+CSDH: 0
+CNMI: 0,0,0,0,1
+ILRR: 0
+IPR: 57600
+CMEE: 2
^SMGO: 0,0
+CSMS: 0,1,1,1
^SACM: 0,"000000","000000"
^SLCC: 0
^SCKS: 0,1
+CREG: 0,1
+CLIP: 0,2
+CAOC: 0
+COPS: 0,0,"operator"
+CGSMS: 3
OK
ACTIVE PROFILE:
E1 Q0 V1 X4 &C1 &D0 &S0 \Q0
S0:000 S3:013 S4:010 S5:008
+CR: 0
+ILRR: 0
+IPR: 57600
+CMEE: 2
^SCKS: 0,1
+CGSMS: 3
OK
