MC55_ATC_V04.00 Page 39 of 475 3/17/06
Confidential / Released
by AT^SCFG="PowerSaver/Mode9/Timeout",<psm9to> (temporary wakeup).
In contrast to SLEEP modes 5,6,7 and 8 assertion of RTS can also be used to
temporarily wake up the ME. In this case too, activity time is at least the time
set with AT^SCFG="PowerSaver/Mode9/Timeout",<psm9to>. RTS can be
activated either from ASC0 or ASC1.
ME exits SLEEP mode only, if AT+CFUN=1 is entered.
The parameter can only be used if the serial interface is enabled.
Due to the command syntax, you need to enter parameter <fun>, followed by <rst>, where <fun> is only a
placeholder and has no effect. See examples below.
[0] Placeholder for <fun> as stated above.
1 ME resets and restarts to full functionality. After reset and restart, PIN 1
authentication is necessary (AT+CPIN). If autobauding is enabled, it is recom-
mended to wait 3 to 5 seconds before entering the first AT command. For
details on autobauding refer to Section 4.7.1, Autobauding.
Notes
• If both serial interfaces ASC0 and ASC1 are connected, any functionality level set with AT+CFUN takes effect
on both of them. In Multiplex mode, the CFUN profile is shared by all multiplexer channels.
• If the ME is in Multiplexer mode, it is not recommended to activate SLEEP mode with AT+CFUN=<fun>. The
best approach to properly control SLEEP mode in this case is to issue the PSC messages described in [5],
Section "Power saving control".
• When a circuit-switched call is in progress, <fun>=7 or 8 or 9 can be activated without terminating the call.
However, setting <fun>=0, 5 or 6 during a circuit-switched call immediately disconnects this call.
• Please keep in mind that power saving works properly only when PIN authentication has been done. If you
attempt to activate power saving while the SIM card is not inserted or the PIN is not correctly entered, the
selected <fun> level will be set, though power saving does not take effect. For the same reason, power sav-
ing cannot be used if MC55 operates in Alarm mode. Furthermore, in order to accept incoming calls, SMS or
network related URCs in SLEEP mode the ME must be registered when it enters the SLEEP mode.
• To check whether power saving is on, you can query the status with the read command AT+CFUN? only if
the module is in full functionality mode or in CYCLIC SLEEP mode. If available, you can also take advantage
of the status LED controlled by the SYNC pin (see AT^SSYNC and [2]). The LED remains "off" while the mod-
ule is in any of the SLEEP modes. However, the module can wake up temporarily from power saving without
leaving its CYCLIC SLEEP mode (without changing +CFUN "<fun>"), e.g. for a network scan after a loss of
radio coverage, or after receipt of serial data during CYCLIC SLEEP mode. During this "temporary wakeup
state" the LED will operate as if the ME was in full functionality mode.
• Recommendation: In NON-CYCLIC SLEEP mode, you can set an RTC alarm to wake up the ME and return
to full functionality. This is a useful approach because, in this mode, the AT interface is not accessible.
Examples
EXAMPLE 1
To check the level of functionality use the read command:
Remember that the AT interface is not accessible in NON-CYCLIC SLEEP mode. Consequently, the read
command is only useful when the ME is set to full functionality or, when <fun> is set to 5, 6, 7, 8 or 9.
EXAMPLE 2
To set the ME to NON-CYCLIC SLEEP mode enter
<rst>
(num)
AT+CFUN?
+CFUN: 1
Default mode after ME was restarted
AT+CFUN?
+CFUN: 5
CYCLIC SLEEP mode
AT+CFUN=0
OK
