MC55_ATC_V04.00 Page 48 of 475 3/17/06

Confidential / Released

302 Operation not allowed

303 Operation not supported

304 Invalid PDU mode parameter

305 Invalid text mode parameter

310 SIM not inserted

311 SIM PIN required

312 PH-SIM PIN required

313 SIM failure

314 SIM busy

315 SIM wrong

316 SIM PUK required

317 SIM PIN2 required

318 SIM PUK2 required

320 Memory failure

321 Invalid memory index

322 Memory full

330 SMSC address unknown

331 no network service

332 Network timeout

340 NO +CNMA ACK EXPECTED

500 Unknown error

512 User abort

513 unable to store

514 invalid status

515 invalid character in address string

516 invalid length

517 invalid character in pdu

518 invalid parameter

519 invalid length or character

520 invalid character in text

521 timer expired

522 Operation temporary not allowed

<err> Code Text (if AT+CMEE=2)
