MC55_ATC_V04.00 Page 61 of 475 3/17/06
Confidential / Released
Parameter Description
0
(&F)
Discard "+CIEV" and "^SLCC" URCs.
1 Discard "+CIEV" and "^SLCC" URCs when TA-TE link is reserved, e.g. in
online data mode. Otherwise they are forwarded directly to the TE.
2 Buffer "+CIEV" and "^SLCC" URCsin the TA while TA-TE link is reserved, e.g.
in online data mode, and flush them to the TE afterwards. Otherwise they are
forwarded directly to the TE.
3Forward "+CIEV" and "^SLCC" URCs directly to the TE. If MC55 is in online
data mode, URCs are signaled via sending BREAK (100ms) and stored in a
buffer. Once it is back in command mode e.g. after +++ was entered, all URCs
stored in the buffer will be output.
0
(&F)
Keypad event reporting is not supported by MC55.
0
(&F)
Display event reporting is not supported by MC55.
0
(&F)
Disable indicator event reporting.
2 Enable indicator event reporting.
0
(&F)
TA buffer of URCs defined within this command is cleared when <mode> 1..3
is entered.
Name of indicator; for a list of all supported indicators please refer to AT+CIND and AT^SIND.
Value of indicator; for a list of all values for the supported indicators please refer to AT+CIND and AT^SIND.
Note
• If the ME operates on different instances (MUX channels 1, 2, 3 or ASC0/ASC1) avoid different settings for
routing and indicating SMS. For example, if messages shall be routed directly to one instance of the TE (set
with AT+CNMI, AT^SSDA), it is not possible to activate the presentation of URCs with AT+CMER or AT+CNMI
on another instance. Any attempt to activate settings that conflict with existing settings on another interface,
will result in CME ERROR, or accordingly CMS ERROR.
<mode>
(num)
<keyp>
(num)
<disp>
(num)
<ind>
(num)
<bfr>
(num)
<indDescr>
(str)
<indValue>
(num)
