Siemens FT724 User Manual

System description
Topology
9
139 |
184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
Floor repeater terminal FT2010
The following settings can be configured in the Operation tree:
● ↑ Visibility
● Cause for activating the LEDs
● Views and commands for the function keys
Floor repeater display FT2011
The following settings can be configured in the Operation tree:
● ↑ Visibility
● Cause for activating an LED
Mimic display
There are two possible ways of configuring the LED indicator (internal) FTO2002
and the LED module FTO2008-A1:
● ↑ Visibility of the 24 LED groups (red/yellow) or (red/green, yellow) on a
↑ Section or Zone.
● Visibility of each of the 48 LEDs on any event.
Mimic display driver FT2001
The mimic display driver activates up to 48 LEDs which are fitted on a ground plan
panel. Communication is via the C-NET.
The mimic display driver also has two control outputs for local buzzer and 'System
On' LED along with two inputs for 'Silence buzzer' and 'START LED test'.
Event printer
The event printer logs all events of the ↑ site in the configured view.
Fire brigade periphery [DE]
The fire brigade periphery comprises the following devices:
● Fire brigade operating panel (FBF)
● Fire brigade key depot (FSD)
● Fire brigade display terminal (FAT)
● FAT with FBF
FSD is assigned to the fire brigade periphery module FCI2001.
FBF can either be connected via the fire brigade periphery module FCI2001 or an
RS485 interface.
FAT and FAT with FBF are connected to the station via a serial interface RS 485.
To configure the devices, the logical element must be created in the 'Operation'
task card and assigned to the corresponding hardware element.
