3.8 Menu structure
MAIN MENU Menu items / Functions Selection / window See page
'Message summary' 'Message summary' Message category Link [➙ 170]
'Functions' 'On / Off' 'Select element category' Link [➙ 45]
'Test' 'Select element category'
'Activate / Deactivate' 'Select element category' Link [➙ 78]
'Information' 'Select element category' Link [➙ 89]
'Configuration' 'Select element category' Link [➙ 92]
'Maintenance' 'Select element category' Link [➙ 175]
'Reports' Station / Module Link [➙ 91]
'All functions' 'Select element category' Link [➙ 62]
'Favorites'
1
e.g. 'Function On/off' 'Select element category' Link [➙ 36]
e.g. 'All functions' 'Select element category' Link [➙ 36]
e.g. 'LED test' LED test Link [➙ 36]
'Topology' ↑ 'Detection tree' 'Area' Link [➙ 69]
'Hardware tree' ↑Station / module Link [➙ 69]
↑ 'Control tree' 'Alarming control group'
/ e.g. 'Evac ct'
1
/ e.g. 'ALARM'
1
/ e.g. 'Fire ct'
1
Link [➙ 69]
'Element search' 'Start with category'
'Select element category' /
Enter address
Link [➙ 71]
'Start with address' Enter address Link [➙ 71]
'Event memory' 'Select station' Events Link [➙ 169]
'Login/logout' Input dialog Link [➙ 58]
'Settings/administration' 'Change language' 'Change language' Link [➙ 103]
'Manage PINs' 'Change PIN'
'Create PIN'
'Delete PIN'
Link [➙ 104]
'LED test' 'LED test' Link [➙ 77]
'Set buzzer volume' 'Set buzzer volume' Link [➙ 105]
'Display settings' 'Display brightness'
'Display contrast'
Link [➙ 106]
'System commands' 'Set system time'
'Activate exp. visibility'
'Deactivate exp.visibility'
Link [➙ 106]
Link [➙ 61]
'Show licence texts' License text is displayed
1
Configurable
See also
1 Settings / Administration [➙ 103]
1 Testing [➙ 74]
