Operation

Changing visibility

61 |

184

Building Technologies

A6V10211076_i_en_

Fire Safety

2015

5.8.2 Activating / deactivating expanded visibility

The '

Activate expanded visibility

' function can be assigned to a favorite to make it

easier to find.

Activation can be configured depending on the condition.

Activating the function 'Expanded visibility'

ϖ The ↑ 'Station' is configured for 'Expanded visibility'.

1. Select 'Main menu' > 'Topology'.

 The three partial trees of the 'Topology' are displayed.

2. Select 'Hardware tree'.

 The elements in 'Hardware tree' are displayed.

3. Select 'Station' and press the 'Lower level' softkey.

 The elements of 'Station' are displayed.

4. Select 'PMI' and press the 'Lower level' softkey.

 The elements of 'PMI' are displayed.

5. Select the 'expand.' element and press the 'More Options' softkey or the

command at the bottom directly, depending on the 'Access level'.

 The 'Selection option' window is displayed depending on the 'Access level'.

6. Select 'Execute commands'.

 The 'Select command' window is displayed.

7. Select 'Activate expanded visibility'

 'Expanded visibility' is activated.

Deactivating the 'Expanded visibility' function

1. Select 'Main menu' > 'Message summary'.

 The message categories containing messages are displayed.

2. Select 'Information'.

3. 'PMI expanded visibility' is shown.

4. Select this element.

5. Press <Execute Commands>.

6. Select 'Deactivate expanded visibility'.

 'PMI expanded visibility' is deactivated.
