Numeric entry
Numeric entry is applicable in the following cases:
● PIN entry (password)
● Shortcuts (Menus)
● Address entry (Element ID)
● Parameter entry
Alphanumeric entry
The alphanumerical input is for entering customer text.
3.6.1 Menu button
= <MENU> button
● The <MENU> button opens the main menu.
● The PIN entry dialog is displayed if no 'Access level' is enabled.
● Opening the main menu is independent from the current display contents.
3.6.2 Button 'ok'
= <ok>, < > = button
With <ok> a selected entry or menu item can be executed or opened.
In windows with an entry field, the <ok> button moves the cursor to the next entry.
3.6.3 Button 'C'
= Cancel button <C>
With <C>, any operation sequence can be cancelled and any open list or window
can be closed.
3.7 LEDs
The LEDs on the ↑Person Machine Interface signal 'Events' and conditions. In
addition, the LEDs support the operator's orientation. The LEDs can light up in red,
yellow, or green. The LEDs can be configured according to customer-specific
requirements.
The LED colors can, for example, signal the following information:
Red ● ALARM
● Activations, e.g., remote transmission,↑ alarm devices,
control function
Yellow ● Fault
● Isolation
● Deactivation, e.g. remote transmission, alarm devices,
control function
Green ● System is in operation
Additional information on the conditions of the LEDs (steady on, steady off or
flashing) can be found in the relevant chapter.
ok
C
